Stirling Cooling System 25L Upright Ultra Low Freezer for Low Temperature Storage

Product Categories

Portable Ultra Low Temperature Freezer [77]
Laboratory Portable Freezer [45]
Household Portable Freezer [42]
Free Piston Stirling Cooler [43]
Portable Storage Freezer [30]
Portable Medical Freezer [73]

Ningbo Juxin Ult-Low Temperature Technology Co., Ltd.

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Stirling Cooling System 25L Upright Ultra Low Freezer for Low Temperature Storage

Ask Lasest Price
Brand Name :	Refport
Model Number :	DM-2525
Price :	$500.00/pieces 5-9 pieces

Add to Cart

Product Details
Company Profile

Stirling Cooling System 25L Upright Ultra Low Freezer for Low Temperature Storage

Specification

Name	Portable Ultra Low Temperature Freezer
Type	DM-2525
Storage Volume	25L
Electric Power	100V AC to 240V AC；50Hz,60Hz；12V DC to 24V DC
Maximum Power	60W (0.5A@220V,4.6A@24V)
Cooling Engine	Free-piston Stirling Engine
Refrigerant	Helium (He)
Heat Transport System	Gravity driven thermosiphon
Temperature Range	25℃ to Minus 25℃
Environmental Conditions	Non-corrosive, Non-flammable, Non-explosive, Altitude up to 2000m
Environmental Conditions		Temperature 5℃ to 35℃,maximum relative humidity 80%
Performance Data	Ambient temperature is 25℃；Empty Cabinet
Performance Data		Take 1.5 hours from 25℃ to -25℃
Steady State Energy	Ambient temperature is 25℃
Steady State Energy		15W
Insulation	High performance vacuum insulated panels, polyurethane foam
Noise	＜55dB
Control Sensor	One RTD(PT100 Class B),precision±0.3
Security	Lockable lid
Warm and cold alarms	Setpoint ±10℃
Defrost Method	Manual
Certification	CE/EMC、CE/LVD、CQC
Interior(LxWxD)	300250300mm
Exterior(LxWxD)	616392455mm
Net Weight, Empty	17.5KG
Shipping(LxWxD)	969472522mm
Shipping Weight	20KG

Our Advantages

Stirling Cooling System 25L Upright Ultra Low Freezer for Low Temperature Storage

Application field

Product Details

Company Profile

Certifications

Product packaging

FAQ

Q&A

Q1. How long will receive the items?
A:Please provide your detail address to us, and we will ask the profession logistics team to figure out it.
Q2.Can I have a sample order?
A:Sure, every item in our company has sample.
Q3.What’s the MOQ?
A:We accept 1 piece order and 10000+ pieces order, The different between them only in price.
Q4.Whether to accept custom or not?
A:We accept OME and ODM, Even OBM is ok.
Q5.What’s Free-piston Stirling engine?
A:FPSC (Free Piston Stirling Cooler) is a new type of completely cfc-free, high efficiency, energy saving and environmental
protection Cooler, which uses a small amount of helium as the coolant. The brief mechanism is that the cylinder (fin) protruding from the main body is cooled by heat exchange, which is a process of repeated cycle of compression, and the stainless steel piston in the main body is constantly moving up and down, resulting in gas explosion.
Q6:What’s the advantages of Free-piston Stirling engine?
A:
1.Oil-Free, Ultra Quiet, Vibration-Free
2.Smallest & Lightest, 2.0kgs (only 1/5 weight of normal compressor)
3.For liquid freezing application, 30% at least energy savings
4.For air cooled application, 50% at least energy savings
5.MagLev technology better reduce system redundancy
6.Ultra compact
7.Light weight
8.Portable
9.Efficient
